TRIO UV 6100 Water Sterilisation System
A high-performance solution offering filtration, purification and amalgam UV sterilisation in a single integrated system.
Technical specifications
View all- Lamp power
- 60 W
- Max. flow rate
- 3.5 m³/h
- Max. pressure
- 16 bar
- Connection size
- 1”
Request received
Our experts will call you.
Free installation
2+8 Year Warranty
24/7 Technical Support
TRIO UV-C protection for professional facilities
The Rainwater TRIO UV 6100 combines three key water treatment processes in a single system, providing complete protection for professional facilities. With amalgam UV lamp technology, 60 W lamp power and a maximum flow rate of 3.5 m³/h, it aims for hygiene, reliability and sustainable use.
Amalgam UV technology
The next-generation amalgam UV lamp delivers high performance and long life with steady, powerful UV radiation.
Three-stage protection
It filters, purifies and sterilises, supporting the physical, taste/odour and microbiological quality of the water together.
Professional applications
Suitable for hotels, restaurants, cafés, cultural facilities, apartment buildings, agricultural applications and industrial facilities.
Chemical-free
UV-C sterilisation provides bacteriological safety without changing the taste or odour of the water.
Highlights
UV-C sterilisation
Water passes through UV-C light; microorganisms are inactivated without the use of chemicals.
Quartz support system
A spring support holds the quartz sleeve in place and protects it during transport.
TRIO UV 6100 Water Sterilisation System
Adding value to your life with certification to international standards
The confidence of flawless quality: freshness and peace of mind for everyday life.
CE certificate
FDA certificate
Water Quality
TÜV Cert ISO 14001
NSF certificate- TÜV Cert ISO 9001
Düzen Norwest
Hacettepe University
Istanbul Technical University
Our systems use PARKER – LIQUIFIT – LEGRIS brand components and comply with the US Food and Drug Administration (FDA) regulations, CFR 21.
Product description
Well, rain or tank water may carry a risk of bacteria and viruses; mains water can also become contaminated in building plumbing and storage tanks. The Rainwater TRIO UV 6100 is a system that sterilises water with UV-C light without using chemicals; it does not change the taste or odour of the water and does not create by-products.
Who is the Rainwater TRIO UV 6100 for?
For apartment buildings and housing estates, hotels, restaurants, cafés, social and sports facilities, agricultural and livestock applications, and places that use rainwater and well water. It sterilises up to 3.5 m³ of water per hour (at a dose of 25 mJ/cm²).
How does it work?
Water passes through a treatment chamber containing a 60 W amalgam UV lamp; UV-C light inactivates microorganisms by preventing them from multiplying. The TRIO system combines three processes in a single integrated system: mechanical filters trap sand, sediment, rust and suspended matter, activated carbon pre-filtration takes place, and then the UV-C unit inactivates any remaining bacteria and viruses without using chemicals.
Technical data
- Connection size: 1”
- Maximum flow rate (25 mJ/cm²): 3.5 m³/h
- Lamp power: 60 W
- Maximum operating pressure: 16 bar
- Maximum temperature: 50 °C
- Water transmittance (min.): 90%
Installation and maintenance
It is installed on the water inlet line. The UV lamp is replaced once a year and the quartz sleeve every 5 years on average. For maintenance, you can submit a request via the technical service form.
Technical specifications
Capacity
- Max. flow rate (at 25 mJ/cm²)
- 3.5 m³/h
Purification
- Water transmittance (min.)
- %90
Power and size
- Lamp power
- 60 W
- Weight
- 10.7 kg
- Connection size
- 1”
- Max. operating pressure
- 16 bar
- Max. operating temperature
- 50 °C
General
- Distributor
- Rainwater Dış Tic. San. ve Tic. A.Ş.
Let's talk about TRIO UV 6100
Our water treatment experts are here for you.
Request received
Our experts will call you.
Frequently asked questions
What does the Rainwater TRIO UV 6100 do?
It sterilises water with UV-C light, inactivating microorganisms such as bacteria and viruses without using chemicals.
Does UV change the taste of the water?
No. UV sterilisation is chemical-free; it does not change the taste or odour of the water and does not create harmful by-products.
What is its flow rate?
It sterilises up to 3.5 m³ of water per hour at a dose of 25 mJ/cm²; the connection size is 1”.
When should the lamp be replaced?
The UV lamp is replaced once a year and the quartz sleeve every 5 years on average.
Is a pre-filter needed?
Yes, it is recommended. Suspended particles prevent UV light from penetrating the water, so mechanical and activated carbon pre-filters are used before the UV unit. In DUO and TRIO systems, the pre-filter is built into the system.
